Intel®11th Gen CoreTM i3/i5/i7 Processor，i3-1115G4/i5-1135G7/i7-1165G7、4x LAN、4x USB3.2；2x USB2.0
OLED production control/SoftPLC motion control/Machine vision inspection/MES edge gateway/AGV vehicle control/Packaging automation
| Product Parameters | ||
| System parameters | CPU | Intel®11th Gen CoreTM i3/i5/i7 Processor，i3-1115G4/i5-1135G7/i7-1165G7 |
| Chipset | Intel® SoC Integrated | |
| BIOS | Insyde BIOS | |
| Memory | 2x SODIMM DDR4，MAX 64GB | |
| Storage | 1x M.2 2280 SSD (SATA/NVMe) | |
| External I/O | Display | 1x DP，MAX 4096 x 2304@60Hz； 1x HDMI，MAX 4K@30Hz |
| Ethernet | 4x LAN，Intel i210 GbE | |
| COM | 2x RS-232/485；2x RS232 | |
| USB | 4x USB3.2；2x USB2.0 | |
| Audio | 1x Mic in; 1x Headphone | |
| Other | Remote | Support remote switching, integrated in the power supply part |
| Reset | Support one-key system restoration by long-pressing | |
| M.2 | 1x M.2 E-Key 2230，support Wi-Fi+BT 1x M.2 B-Key 3052，support 4G/5G； | |
| SIM | 1x Nano SIM | |
| TPM | Support，Reserved | |
| System | OS | Windows 10 22H2、Linux |
| Power supply | Input voltage | 24V DC IN，4PIN Phoenix |
| Power | MAX 120W | |
| Mechanical parameters | Iinstallation | Wall-mounted installation (rail optional) |
| Dimensions | 236 x 165 x 63.5mm（LxWxH） | |
| Net weight | 2.2 kg | |
| Environmental parameters | Operating temperature | 0~50°C，with an air flow of 0.7 meters per second |
| Storage temperature | -20°C ~60°C， 60°C @ 95% (non-condensing) | |
| Relative humidity | 10 ~ 95% @ 40°C (non-condensing) | |
| EMC | CE、FCC | |
| Ordering information | |||||
| Model | CPU | MEM | SSD | HDD | Expansion Module |
| HG511D-C11XXX | I5-1135G7 | 8G/16G/32G /8G*2/16G*2 /32G*2 | 128G/256G/512G/1T/2T | / | 4G/WiFi |
